Sicma TR-50 Olive Harvester – 3PL

TR-50 Olive Harvester

Sicma TR-50 Semi-trailed harvester for small to medium-sized harvesting needs of olives, walnuts, almonds, pecans, pistachios and other hanging fruits. It is connected to the tractor by the 3-point hitch system and operated by the PTO with an independent hydraulic circuit. The TR-50 has a telescopic arm (double extension) supporting the New Generation Vibrating Head suitable for the harvest of tree trunks and/or branches of medium size, up to 5 m height. It requires a tractor of at least 60 Hp. The reverse umbrella cannot be coupled on this model.

Sicma TR-50 – TR-80 Brochure

Specification

HOOKING & ACTUATION: 3-point hitch system and cardan power shaft (PTO 540)
TELESCOPIC ARM: Triplex with double telescopic extensions (2.000 mm)
ARM ROTATION: Both sides, at 42° respect to the longitudinal line
VIBRATING HEAD: New Generation at high frequencies, self-centring and self-braking. Two vibrating speeds
CONTROLS: Service hydraulic lever distributor with 7 levers
HYDRAULIC CIRCUIT: Closed hydraulic circuit composed by vibration pump, services pump, heat exchanger and hydraulic steering support. Hydraulic oil tank separated from the tractor circuit

SIZE & WEIGHT:

TOTAL LENGTH: 3.625 mm (centerwheel-extension retracted arm)
MAX HEIGHT: 4.500 mm (with extended arm)
MAX WIDTH: 2.250 mm
TOTAL WEIGHT: 1.648 kg
